Update Smargo Firmware

admin

If no automatic update is set for the inverter in the communication product (e.g. SMA Data Manager, Cluster Controller, Sunny Portal) or via the user interface of the inverter, you have the option of carrying out a manual firmware update.

Smargo Smartreader V2 Possibilities EXTRA CARDREADER For eg: Octagon SF-1018 HD PVR Linux Twin, Dreambox, Reelbox, Triple Dragon, Linux PC or Windows PC. Jan 29, 2014 smartreader+ 1,4 firmware - posted in EN The Lounge: Does anybody have the 1.4 firm version of Smargo v1 updater? ( srpupdatemipsel? ) I have 2 new v1 smargos which come with 1.3, and I need to update them to 1.4 because of ID name which is enabled on v 1.4 Ive tried the windows smartreaderupdate.exe 1.4 program, but I cant update, progress bar stays always at 0.

There are two options to update the firmware:

Update Smargo Firmware 10

  • Update the firmware via the user interface of the inverter.

  • Update the firmware via USB flash drive.

Updating firmware via the user interface

Requirements:

  • An update file with the desired inverter firmware must be available. The update file is, for example, available for download on the product page of the inverter at www.SMA-Solar.com. To download the update file, it is necessary to enter the serial number of the inverter.

Update Smargo Firmware

Procedure:

Update Smargo Firmware Windows 10

  1. Activate the user interface ( > Establishing a connection to the user interface).
  2. Log into the user interface ( > Logging In and Out of the User Interface).
  3. Select the menu Device Configuration.
  4. In the inverter row, click on the gear icon and select Update firmware.
  5. Select [Browse] and select the update file for the inverter.
  6. Select Update firmware.
  7. Follow the instructions in the dialog.

Updating the Firmware via USB Flash Drive

Requirement:

Update smart firmware

  • A USB flash drive with maximum 32 GB and file system FAT32 must be available.

Procedure:

Firmware

Update Smargo Firmware Windows 7

  1. Create an 'UPDATE' folder on the USB stick.
  2. Save the update file with the desired firmware in the 'UPDATE' folder on the USB flash drive. The update file is, for example, available for download on the product page of the inverter at www.SMA-Solar.com. Make sure that only the update file to which the inverter is to be updated must be saved on the USB flash drive.

    3. Danger to life due to high voltages

    1. Disconnect the inverter from any voltage sources and open the enclosure lid of the Connection Unit (see the inverter installation manual).
  3. Insert the USB flash drive in the USB port on the communication assembly.
  4. Commission the inverter (see inverter installation manual).
  5. During start-up phase of the inverter, the desired firmware is being installed. At the same time, the status of the update is shown in the display: Update status: xxxxxxx
  6. Once the desired firmware has been installed in the inverter, the status successful is shown in the display.
  7. If the message error occurred is shown in the display, perform the firmware update again.

    8. Danger to life due to high voltages

    1. Disconnect the inverter from any voltage sources and open the enclosure lid of the Connection Unit (see the inverter installation manual).
  8. Pull the USB flash drive out of the USB port.
  9. Commission the inverter (see inverter installation manual).
